本圖集適用于民用公共建筑和一般工業建筑內設置的附屬式公用建筑衛生間。 本圖集主要內容為：各類公共建筑衛生間的設計要點和典型平面示意，包括學校、宿舍、商業、餐飲、旅館、酒店、辦公和文體、交通、工業等建筑的衛生間及其他特殊衛生間。還包含了衛生間設施構造及安裝詳圖。 圖集按照新的標準編制，對原圖集02J915《公用建筑衛生間》進行修編，除新增了交通、文體、商業等類型建筑的衛生間外，還增加了母嬰室、第三衛生間等內容，對不同類型建筑的衛生間進行了細化，更新了廁位比例，進一步擴大了適用范圍。圖集內容豐富、品種多樣、構造詳細、實用性強，滿足廣大設計和施工工作的使用需求。

目錄······5

總說明······8

廁位及潔具設計要點······13

廁位及潔具凈距······14

A 學校、宿舍建筑衛生間······16

A型衛生間說明······16

Al型衛生間······18

A2型衛生間······19

A3、A4型衛生間······20

B 商業建筑衛生間······21

B型衛生間說明······21

Bl、B2型衛生間······22

B3、B4型衛生間······23

B5、B6型衛生間······24

C 餐飲建筑衛生間······25

C型衛生間說明······25

C1型衛生間······26

C2型衛生間······27

D 旅館、酒店建筑衛生間······28

D型衛生間說明······28

D型衛生間······29

D1型衛生間單元圖······31

D2型衛生間單元圖······32

D3型衛生間單元圖······33

E 文體建筑衛生間······34

E型衛生間說明······34

E1型衛生間······35

E2型衛生間······36

E3 型衛生間······37

F 交通建筑衛生間······38

F型衛生間說明······38

F1型衛生間······39

F2型衛生間······40

F3型衛生間······41

F4型衛生間······42

G 辦公、工業建筑衛生間······43

G型衛生間說明······43

G型衛生間······44

H 其他特殊衛生間······45

女員工衛生室······45

母嬰室······46

第三衛生間······47

XT 詳圖······48

廁位詳圖······48

無障礙廁位詳圖······49

無障礙衛生間詳圖······51

淋浴間詳圖······52

更衣室詳圖······54

衛生間隔斷類型······55

衛生間隔斷詳圖······56

洗手盆詳圖······58

浴盆詳圖······60

小便器、婦洗器安裝詳圖······62

小便槽詳圖······63

坐便器安裝詳圖······64

蹲便器安裝詳圖······65

蹲便器及衛生間入口詳圖······66

隱蔽式水箱安裝詳圖（一）······67

隱蔽式水箱安裝詳圖（二）······68

單面盥洗槽詳圖······69

雙面盥洗槽詳圖······70

清潔池詳圖······71

衛生間配件詳圖（一）······72

衛生間配件詳圖（二）······73

衛生間配件詳圖（三）······74

衛生間配件詳圖（四）······75

衛生間配件詳圖（五）······76

衛生間配件安裝詳圖······77

附錄······79

衛生潔具技術資料······79

先進環保的潔具技術資料······81

衛生間實例······82
